4G LTE Wireless Quad Band GPS Tracker Device With 10-90V Wide Input Voltage
TBIT WD-100 is based on the 4G LTE, and equipped with multiple mode locate, so that outdoor positioning distance is accurate to 5 meters.
The device builds in GPS and GSM double antennas , which can realize real -time tracking and monitoring. It has the functions of smart save power , easy installation,plug - and - play and wide range input voltage and so on .
Functions:
- 4G-LTE network
- GSM Quad - band: 4GLTE B1/B3/B5/B7/B8/B20@FDD LTE B38/B40/B41@TDD LTE B1/B5/B8@WCDMA B3/B8@GSM
- Built-in acceleration sensor for vibration alarm
- Record speed data
- Geo-fence settings and alarm
- Vehicle history playback
- 10-90V wide input voltage
- Easy installation
More Details:
- Accurate location: high level of receive sensitivity and very short time for positioning. Assisted GPS to short cold-start in 35 seconds
- Dual mode coverage: GPS and LBS based on mobile wireless network support seamless coverage of positioning in special area such as indoor, channel and basement
- Backup battery: Standby in 8-12 hours in full-load mode, and 5 days in normal situation
Tracking method: There are three way for tracking, PC platform, mobile APP both IOS and Android, you can click this link to choose any one by yourself http://www.gpssky.net/
| | Dimension | | 78.5*52*20mm | | Weight | | Net: 57g, Gross: 176g |
| | Working voltage | | 10-90V | | Power consumption | | 30-35 mA working mode and 3-5mA sleepmode |
| | Battery | | 550 mAh/3.7 V rechargeable and replaceable lithium-ion battery | | Operating temperature | | -20°C to 65°C |
| | Humidity | | 5%–95% | | Standby time | | 4-6 days hours in power-saving mode and 8-10 hours in tracking mode |
| | LED indicator | | 3 indicators showing power, GSM, SIMCARD and GPS status | | Other Functions | | Acc detective oil cut-off |
| | GPS | | Support AGPS | | Positioning accuracy | | 5m |
| | Sensor | | 3D acceleration sensor | | GSM frequency band | | 4GLTE B1/B3/B5/B7/B8/B20@FDD LTE B38/B40/B41@TDD LTE B1/B5/B8@WCDMA B3/B8@GSM |
Our service:
-- Direct factory and strong R&D team
-- Over 10 years specialize in gps tracker
-- Support Android/ IOS APP
-- Certificate:CE, ROHS, CTA, CCC
-- Support multi languages customized
Platform service:
-- Platform fee is free all life
-- Vehicle Monitoring, Safety Tracking and management
-- Agency Management center
-- Open API to integrate your server or platform
Equipped with ACC detection and oil cut-off easy-to-use GPS tracking system, you can implement real-time tracking anywhere through a mobile phone or laptop.
FAQ:
Q: What is the minimum order quantity?
A: No limit, standard 20pcs/ctn, better to fill up one full carton, also accept sample order. For OEM, with your logo and platform, MOQ 2000pcs.
Q: What is the guarantee of the device?
A: We supply one year warranty.
Q: What payment method do you accept?
A: T/T, L/C, Western Union ect.
Q: How will you deliver goods to me?
A: We always send sample order by Express, ship mass order by Air, Sea, Express, according to clients’choice.
Q: Sometimes location is not accuracy?
A: There are two way location, GPS outdoor, more accuracy, LBS indoor, less accuracy, since LBS bases station location, location accuracy is involved in satellite signals and network intensity.
Q: How about the lead time?
A: Standard sample always in stock, 3-5 working days for regular order less than 2000pcs, 10-15 working days for mass production order(based on different quantity.
